Can You Hear Me Now with DMR?

When folks talk about distances of radio communication systems or networks, people find it difficult to translate descriptions into mental pictures, so this writer set out to bridge the gap between numbers and meaningful graphics.

I wanted to view coverage maps as I have seen by the National Weather Services’ NOAA Weather Radio, and commercial radio and TV station plots, but Digital Mobile Radio coverage maps are rare, so I decided to make my own thanks to the technology and the internet.

While researching, I found that the Mansfield DMR repeater antenna is MOAA (Mother of All Antennas) in the state of Ohio. This antenna has a reported height of 984.2 feet AGL. No other DMR antenna comes close to this reported height in the state.

The Mansfield coverage area alone extends to just north of Columbus, west to Findlay, north to Lake Erie, and west of Wooster, Massillon and Medina. East of this area, signal strength is weak and would not provide reliable or consistent communications.

Mansfield’s main coverage area is impressive; encompassing 6,783.04 square miles with signal strength of 1.55 microvolts or better. Foliage, valleys, hills, structures, etcetera, should be taken into consideration if operating.

When factoring the extended and/or fringe areas, the Mansfield area grows to 9,594.253 square miles of 0.5 microvolts of signal strength or better, reaching 2.55 million Ohioans and many thousands of amateur radio operators.

According to the U.S. Geological Survey, Ohio is the 35th largest state in the U.S. and the Mansfield DMR repeater covers 23.43 percent of the state.

Mansfield DMR “MOAA” covering 23.43 percent of Ohio.

I obtained as much reported antenna height information as I could pertaining to the other 64 Ohio DMR repeater antenna heights, and then interpolated heights where no information was found. I used a 100-foot height for those DMR repeaters. I wanted to see the overall coverage area for all of Ohio.

When processing and merging all known and unreported DMR antenna heights for analysis, a statewide map emerged.

False color DMR coverage map for Ohio.

This map reveals about 70 percent of Ohio has some DMR coverage. False colors were introduced to emphasize signal coverage. The color pink is good to strong coverage while the blue is marginal to good coverage. The black, as seen in the lower right corner has no discernable coverage, and extends into West Virginia and western Pennsylvania.

Extreme eastern and most of southeast Ohio are in dire need of some kind of coverage. Interstate highway coverage, west of I-77 has ample coverage, but more overlapping coverage is desirable.

This link is a Google map that displays reported DMR repeaters in a five-state region including Kentucky, Illinois, Indiana, Michigan, Ohio, and is of interest if one is traveling in the Midwest:

In the near future, Coshocton and Tuscarawas County may see DMR repeaters as those respective areas have plans to install equipment. With patience, Ohio amateur radio operators may have complete, statewide access to DMR.

Update note:  It was announced on or about June 17 that Richmond, Ind., is planning to install a DMR repeater that will help increase coverage along I-70 in west central Ohio.
